1.8OZ Electronic Printed Circuit Board For Air Conditioning Systems
| Place of Origin | Shenzhen |
|---|---|
| Brand Name | YScircuit |
| Certification | ISO9001,UL,REACH, RoHS |
| Model Number | YS-PCBA-0020 |
| Minimum Order Quantity | 1 piece |
| Price | 0.17-9$/piece |
| Packaging Details | Foam cotton + carton + strap |
| Delivery Time | 2-8 days |
| Payment Terms | T/T，PayPal, Alibaba pay |
| Supply Ability | 251,000 square meter/year |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Material | FR4+Component Parts | Size | 40*36cm |
|---|---|---|---|
| Process | Immersion Gold | Surface Finishing | HASL/HASL-LF/ENIG/OSP |
| Product Name | Air Conditioning Systems PCBA | Application | Air Conditioning Systems |
| Base Material | FR-4 | Copper Thickness | 1.8 OZ |
| High Light | 1.8OZ Electronic Printed Circuit Board,1.8OZ electronics pcb pcba,1.8OZ circuit board pcba |
||
Product Description
1.8OZ Electronic Printed Circuit Board For Air Conditioning Systems
Industry PCBA OEM PCB And Component Assembly For Air Conditioning Systems
Printed Circuit Board Assembly (PCBA)
For over one decades, YScircuit has been committed to assembling high quality printed circuit board assemblies for our clients.
Whether they ship as a final product or a PCBA alone, we produce PCBAs that meet even the most stringent requirements.
Our passion for building quality into the PCBAs through strict process control, combined with feedback systems such as 100% automated optical inspection and in-circuit testing, help drive our pursuit of continuous quality improvement.
- Fast turn protos through mid-volume
- Automated Surface Mount Technology (SMT)
- BGA and Fine Pitch Component Placement
- Thru-hole PCBA Assembly
- Wave (tin-lead) and Selective Solder (RoHS)
- Multiple Solder Chemistry Options (No-Clean, Water Soluble, RoHS, Leaded)
- IPC-A-610 Class 2 and 3
- Advances Automated Cleaning Systems
- Conformal Coating
- Automated Optical Inspection
- Broad Testing Portfolio (ICT, Parametric, Functional)
- Device Programming
| Capability | Standard |
| Certifications: | ISO 9001: 2015, AS 9100 Rev D, ISO 13485: 2016 |
| Lead Time: | 1-5 Days, As per the scheduled period |
| Parts procurement: | Full Turnkey, Partial Turnkey, and Knitted |
| Assembly Types: | Surface Mount (SMT), Thru-hole, Mixed Technology, Single and double-sided SMT/PTH. |
| Stencils: | Laser cut stainless steel and Nano-coating |
| Components: | Passive components smallest size 0201, Fine pitch components smallest size 8 Mils pitch. |
| Component packaging: | Reels, Cut Tape, Tube, and lose parts. |
| Inspection: | X-ray analysis, AOI, and Microscope to 20X |
| Solder Type: | Leaded and Lead-free/ RoHS compliant |
| Assembly Surface mount connectors: | Yes |
| Wave Soldering: | Yes |
| PCB Finish: | SMOB/HASL, Electrolytic gold, Electroless gold, Electroless silver, Immersion gold, Immersion gold, Immersion tin, and OSP. |
| Panelized PCB: | Tab routed, Breakaway tabs, V-scored and Routed + V scored |
| Rework: | BGA removal and replacement station, SMT IR rework station, and Thru-hole reworks station. |
| Design file format: | Gerber RS-27, 274D, Eagle and Auto CAD's DXF, DWG BOM, and Pick and place a file |
| layer/m² | S＜1㎡ | S＜3㎡ | S＜6㎡ | S＜10㎡ | S＜13㎡ | S＜16㎡ | S＜20㎡ | S＜30㎡ | S＜40㎡ | S＜50㎡ | S＜65㎡ | S＜85㎡ | S＜100㎡ |
| 1L | 4wds | 6wds | 7wds | 7wds | 9wds | 9wds | 10wds | 10wds | 10wds | 12wds | 14wds | 15wds | 16wds |
| 2L | 4wds | 6wds | 9wds | 9wds | 11wds | 12wds | 13wds | 13wds | 15wds | 15wds | 15wds | 15wds | 18wds |
| 4L | 6wds | 8wds | 12wds | 12wds | 14wds | 14wds | 14wds | 14wds | 15wds | 20wds | 25wds | 25wds | 28wds |
| 6L | 7wds | 9wds | 13wds | 13wds | 17wds | 18wds | 20wds | 22wds | 24wds | 25wds | 26wds | 28wds | 30wds |
| 8L | 9wds | 12wds | 15wds | 18wds | 20wds | 20wds | 22wds | 24wds | 26wds | 27wds | 28wds | 30wds | 30wds |
| 10L | 10wds | 13wds | 17wds | 18wds | 20wds | 20wds | 22wds | 24wds | 26wds | 27wds | 28wds | 30wds | 30wds |
| 12L | 10wds | 15wds | 17wds | 18wds | 20wds | 20wds | 22wds | 24wds | 26wds | 27wds | 28wds | 30wds | 30wds |
| 14L | 10wds | 16wds | 17wds | 18wds | 20wds | 20wds | 22wds | 24wds | 26wds | 27wds | 28wds | 30wds | 30wds |
| 16L | 10wds | 16wds | 17wds | 18wds | 20wds | 20wds | 22wds | 24wds | 26wds | 27wds | 28wds | 30wds | 30wds |
FQA
Q: How long have you been making PCB&PCBA?
A: PS has been making PCBs for more than 10 years. We built our assembly plant and begin assembly business in 2005.
Q: How do I get a quick quote for PCB or PCB Assembly?
A:Please send your files and requirements to us by email info@yscircuit.com. Quote will be sent back as soon as we get through an evaluation.
Q: What documents do you need for production&assembly?
A: For PCB please provide Gerber data (RS-274-X) or PCB layout files such as Altium file and special requirements if you have.
For PCBA please provide the same documents as PCB meanwhile BOM (bill of materials) & CPL (Component Placement List).
Besides if you need function test please include the test instruction.
Q: Are my PCB files safe when I submit them to you?
A: We respect customer's copyright and will never manufacture PCB for someone else with your files unless we receive written NDA agreement & ERP system are running to ensure that.
Q: No PCB file/GBR file only have the PCB sample can you produce it for me?
A: Yes we could help you to clone the PCB. Just send the sample PCB to us we could clone the PCB design and work out it.
Q: Do you offer lead-free assembly?
A: Of course we provide RoHS lead-free assembly.
