DQS Electronic Co., Limited
|
| MOQ: | 1 |
| Price: | Send us Gerber file for free quotation |
| Payment Terms: | T/T |
A printed circuit board (PCB) is a flat board made of insulating material (like fiberglass) with thin layers of copper traces printed or etched onto its surface. These copper traces act as electrical pathways that connect various electronic components—such as resistors, capacitors, and integrated circuits—mounted on the board. PCBs are essential in almost all electronic devices, providing a reliable and compact way to support and connect components without loose wires.
| Item | Specification |
|---|---|
| Layers | 1~32 |
| Board thickness | 0.1mm-7.0mm |
| Material | FR-4, CEM-1/CEM-3, PI, High Tg, Rogers |
| Max panel size | 32"×48"(800mm×1200mm) |
| Min hole size | 0.075mm |
| Min line width | 3mil(0.075mm) |
| Surface finish | OSP, HASL, Imm Gold/Nickel/Ag, Electric gold |
| Copper thickness | 0.5-7.0OZ |
| Soldermask | Green/Yellow/Black/White/Red/Blue |
| Silkscreen | Red/Yellow/Black/White |
| Min PAD | 5mil(0.13mm) |
| Inter package | Vacuum |
| Outer package | Carton |
| Outline tolerance | ±0.75mm |
| Hole tolerance | PTH:±0.05 NPTH:±0.025 |
| Certificate | UL, ISO 9001, ISO14001, IATF16949 |
| Special request | Blind hole+Gold finger + BGA |
| Material Suppliers | Shengyi, KB, Nanya, ITEQ, etc. |
