DQS Electronic Co., Limited
|
| MOQ: | 1 |
| Price: | Inquiry Us |
| Payment Terms: | T/T |
| PCB Specification | Normal | Special |
|---|---|---|
| Length and Width (L*W) | Minimum: L≥3mm, W≥3mm Maximum: L≤800mm, W≤460mm |
L＜2mm L＞1200mm, W＞500mm |
| Thickness (T) | Thinnest: 0.2mm Thickest: 4mm |
T＜0.1mm T＞4.5mm |
| SMT Components Specification | Normal | Special |
|---|---|---|
| Outline Dimension | Min size: 0201 (0.6mm*0.3mm) Max size: 200*125 |
01005 (0.3mm*0.2mm) 200*125 |
| Component Thickness | T≤15mm | 6.5mm＜T≤15mm |
| QFP, SOP, SOJ (multi pins) | Min pin space: 0.4mm | 0.3mm≤Pitch＜0.4mm |
| CSP/BGA | Min ball space: 0.5mm | 0.3mm≤Pitch＜0.5mm |
| PCB Specification | Normal | Special |
|---|---|---|
| Length and Width (L*W) | Minimum: L≥50mm, W≥30mm Maximum: L≤1200mm, W≤450mm |
L＜50mm L≥1200mm, W≥500mm |
| Thickness (T) | Thinnest: 0.8mm Thickest: 3.5mm |
T＜0.8mm T＞2mm |
