Metal Core Copper Base PCB Assembly OEM For Electronic CPU Board

Metal Core Pcb OEM Pcba Copper Base Print Circuit Board For CPU Board

The Reasons Why Choose Our Copper PCBs

1. Excellent heat dissipation, especially in high power and LED products.

Conventional materials such as FR4 and CEM3 do not meet the required high thermal conductivity, meanwhile, aluminum PCBs also perform poorly under some harsh conditions, which will lead to parts damaging because of failure to dissipate heat.

The excellent heat dissipation performance of the copper PCB can solve this problem.

2. Dimensional stability, temperature raises from 30°C to 140 ~ 150°C, the size change of copper PCB is 2.5~3.0%.

3. Excellent mechanical properties.

4. Replacement of heat sink, to save PCBs' spacing

Single Layer Metal Core PCB Stack up

Double Layer Metal Core PCB Stack up

Multilayer Metal Core PCB Stack up

FQA

1. What is the thickness of a metal core PCB?
The thickness of the metal core in a PCB substrate is typically 30 mil - 125 mil, but thicker and thinner boards are possible.

2. What are the advantages of metal core board?
Metal core boards transfer heat 8 to 9 times faster than FR4 PCBs.
These metal core laminates keep heat-generating components cool by dissipating heat faster.
The dielectric material is kept as thin as possible in order to create the shortest path from the heat source to the metal backplane.

3. How is a metal core PCB made?
If the board is a single-layer board with no layers transitioning back to the metal plate, the dielectric layers can be pressed and bonded to the metal plate using the standard process used with FR4 dielectrics.

4. What is a metal core PCB?
A metal core printed circuit board (MCPCB) is a printed circuit board that contains base metal materials.
The core is designed to transfer heat away from components that generate a lot of heat.
