Internal Copper 1.2mil PCB Manufacturing Services Offering Minimum Line Space 0.10mm and Minimum Hole Size 0.2mm for Precision Electronics

Detail Information

Product Description

Detail Information

Minimum Line Space:

0.10mm

Special Capability:

Gold Finger Plating,Carbon Ink

Min Space:

0.075mm

Board Type:

Rigid, Flexible, Rigid-flexible

Tolerance Of Pth:

+/-0.05mm

Hole Min:

0.1mm

Materials:

Rogers, Nelco, PTFE, M6, TU862, TU872

Application:

Electronics Device,Consumer Electronics

Highlight:

Internal Copper PCB manufacturing services

Precision PCB with 0.10mm line space

PCB manufacturing with 0.2mm hole size

Product Description

High-Precision PCB Manufacturing Services

Our PCB manufacturing services deliver exceptional precision for electronics devices and consumer electronics applications. With advanced multilayer PCB manufacturing processes, we ensure reliable performance and consistent quality for demanding electronic designs.

Key Features

Product Name: PCB Manufacturing
Special Capability: Gold Finger Plating and Carbon Ink
Internal Copper Thickness: 1.2mil
Component Sourcing Available
Minimum Hole Size: 0.2mm
SMT Capability: 14 Million Spots Per Day
Expertise in PCB Assembly and Manufacturing
Custom PCB Manufacturing Service tailored to your needs
High-quality Electronic Circuit Board Production

Technical Specifications

Layer Count	1-48
Board Type	Rigid, Flexible, Rigid-flexible
Hole Min	0.1mm
Min Space	0.075mm
SMT Capability	14 Million Spots Per Day
Internal Copper Thickness	1.2mil
Component Sourcing	Yes
Tolerance of PTH	+/-0.05mm
Materials	Rogers, Nelco, PTFE, M6, TU862, TU872
Minimum Line Space	0.10mm

Applications

Our high-precision PCB manufacturing is ideal for consumer electronics, medical instruments, automotive electronics, and industrial control systems. The precise tolerance of plated through holes at +/-0.05mm and internal copper thickness of 1.2mil ensure excellent electrical conductivity and mechanical stability for demanding applications.

Customization Options

We offer high precision PCB fabrication with copper thickness ranging from 0.5OZ to 10OZ, supporting minimum hole size of 0.2mm for intricate circuit designs. With SMT capability of 14 million spots per day and advanced materials including Rogers, Nelco, PTFE, M6, TU862, and TU872, our multilayer PCB manufacturing process meets the highest industry standards.

Frequently Asked Questions

What types of PCB materials do you offer for manufacturing?

We offer a variety of PCB materials including FR4, CEM-1, Rogers, Aluminum, and flexible substrates to suit different applications and requirements.

What is the typical turnaround time for PCB manufacturing?

Our standard turnaround time ranges from 3 to 7 business days depending on the complexity and quantity of the order. Expedited services are also available upon request.

What is the maximum PCB size you can manufacture?

We can manufacture PCBs up to 24 inches by 18 inches. For larger sizes, please contact our support team for custom solutions.

Do you support multi-layer PCB fabrication?

Yes, we support multi-layer PCBs ranging from 2 layers up to 32 layers, allowing for complex circuit designs and high-density interconnections.

Can I order prototype PCBs in small quantities?

Absolutely! We accommodate prototype and small batch orders starting from just 1 piece, enabling rapid development and testing cycles for your projects.
