ODM Automotive PCBA Assembly 6 Layer Board Fabrication 01005

MOQ:	1
Price:	Contact our PCB engineer
Payment Terms:	T/T

Detail Information

Product Description

Detail Information

Layer:

Board Thickness:

1.0mm

Min. Component Size:

01005

Surface Finish:

ENIG

Pin Space:

0.1mm

Test:

AOI,FCT,ICT

Service:

PCBA/SMT/DIP / PCBA Layout And Design

Application:

Automobile Control System

Highlight:

ODM Automotive PCBA

01005 Automotive PCBA

ODM pcb assembly board

Product Description

Automotive PCBA High Current Carrying OEM Assembly

♦ What's Automotive PCBA?

Automotive PCBA, or automotive printed circuit board assembly, is a finished product formed by assembling electronic components onto automotive printed circuit boards (PCBs) through welding and other processes. It is the core carrier of automotive electronic systems and is widely used in automotive power systems, body control, safety assistance, infotainment, and autonomous driving systems, such as engine control units, battery management systems, and anti-lock braking systems.

♦ Features of Automotive PCBA

Versatile Applications: It is used in engine control units for precise control of engine parameters, body control modules for managing various vehicle electrical systems, and autonomous driving systems to support ADAS and fully autonomous driving functions.
High Reliability: Built to endure harsh automotive environments like extreme temperatures, vibrations, and electromagnetic interference. Uses high-grade components and advanced protection circuits to ensure long-term reliability.
Intelligent and Automated: Incorporates intelligent algorithms and technologies to improve system performance and efficiency, and supports automation in manufacturing processes

♦ Types of Automotive PCB Assemblies:

Application	PCB Requirements	Examples
Engine Control Unit (ECU)	High-temperature resistance, EMI shielding	Fuel injection, ignition timing
Infotainment System	High-speed signal integrity, multilayer	Touchscreens, GPS, Bluetooth
ADAS (Radar/LiDAR)	RF/microwave PCBs, low-loss materials	Collision avoidance, adaptive cruise control
EV Battery Management (BMS)	High-current PCBs, thermal management	Cell balancing, charge monitoring
LED Lighting	Aluminum PCBs for heat dissipation	Headlights, interior lightin

♦ DQS's PCB Assembly Capability

Item				Normal	Special
SMT Assembly	PCB(used for SMT) specification	Length and Width( L* W)	Minimum	L≥3mm, W≥3mm	L＜2mm
		Length and Width( L* W)	Maximum	L≤800mm, W≤460mm	L ＞ 1200mm, W＞500mm
		Thickness( T)	Thinnest	0.2mm	T＜0.1mm
		Thickness( T)	Thickest	4 mm	T＞4.5mm
	SMT components specification	Outline Dimension	Min size	0201(0.6mm*0.3mm)	01005(0.3mm*0.2mm)
			Max size	200 * 125	200 * 125
			component thickness	T≤15mm	6.5mm＜T≤15mm
		QFP,SOP,SOJ (multi pins)	Min pin space	0.4mm	0.3mm≤Pitch＜0.4mm
		CSP/ BGA	Min ball space	0.5mm	0.3mm≤Pitch＜0.5mm
DIP Assembly	PCB specification	Length and Width( L* W)	Minimum	L≥50mm, W≥30mm	L＜50mm
		Length and Width( L* W)	Maximum	L≤1200mm, W≤450mm	L≥1200mm, W≥500mm
		Thickness( T)	Thinnest	0.8mm	T＜0.8mm
		Thickness( T)	Thickest	3.5mm	T＞2mm
