Lighting PCB Assembly
Created with Pixso.

Low Heat Radiation Flexible Led PCB Assembly For Medical Lighting Driver

Low Heat Radiation Flexible Led PCB Assembly For Medical Lighting Driver

MOQ: 1
Payment Terms: T/T
Detail Information
Layer:
8L
Base Material:
Al
Board Thickness:
2.0mm
Testing Method:
Flying Probe And AOI (Default)
Min. Line Width/Spacing:
0.1mm
Surface Finish:
HASL, ENIG, OSP
PCB Assembly Method:
Mixed,BGA,SMT,Through-hole
Application:
Medical Lighting
Highlight:

Medical Lighting flexible led pcb

,

flexible led pcb Assembly

,

led driver pcb Assembly

Product Description

Low Heat Radiation Lighting PCB Assembly​ Can Be Customized for Medical Lighting



♦ What is Lighting PCB Assembly?



​Lighting PCB Assembly is a specialized electronic assembly that integrates circuit boards with lighting components (e.g., LEDs, drivers) and control systems. It serves as the core functional unit in diverse lighting applications, combining electrical connectivity, thermal management, and intelligent control to enable efficient, durable, and feature-rich lighting solutions.



♦ Features of Medical Lighting LED PCBA​​

    • ​​High color rendering without flicker: CRI≥95 restores true colors, constant current drive eliminates flicker, and ensures diagnosis/surgery accuracy.

    • Precise light control: supports stepless dimming, color temperature adjustment and spot control, adapting to multiple scene requirements.

    • Strong heat dissipation: metal substrate + efficient thermal conductivity design to ensure high power and long-term stable operation.

    • Low electromagnetic interference: complies with IEC 60601-1-2 medical EMC standards to avoid instrument interference.



♦ Applications of Lighting PCBA:

    • ​Residential & Commercial Lighting​​: Decorative fixtures, recessed lighting, panel lights, and architectural accents.
    • Automotive​​: Interior ambient lights, dashboard backlights, and signal indicators.
    • Industrial​​: Machine indicator lights, warehouse lighting, and harsh-environment fixtures.
    • Consumer Electronics​​: Backlights for screens, keyboard illumination, and appliance status lights.



♦ Technical Parameters



 PCB Assembly Capability



Item



                  Normal



 Special

















SMT

Assembly





PCB(used for SMT)

specification

Length and Width( L* W)

Minimum

L≥3mm,  W≥3mm

L<2mm

Maximum

L≤800mmW≤460mm

L > 1200mmW>500mm

Thickness( T)

Thinnest

0.2mm

T<0.1mm

Thickest

4 mm

T>4.5mm



SMT components specification

Outline Dimension

Min size

0201(0.6mm*0.3mm)

01005(0.3mm*0.2mm)

Max size

200 * 125

200 * 125

component thickness

T≤15mm

6.5mm<T≤15mm

QFP,SOP,SOJ

(multi pins)

Min pin space

0.4mm

0.3mm≤Pitch<0.4mm

CSP/ BGA

   Min ball space

0.5mm

0.3mm≤Pitch<0.5mm





DIP

Assembly



PCB specification



Length and Width( L* W)

Minimum

L≥50mm, W≥30mm

L<50mm

Maximum

L≤1200mm, W≤450mm

L≥1200mmW≥500mm

Thickness( T)

Thinnest

0.8mm

T<0.8mm

Thickest

3.5mm

                      T>2mm





♦ One-Stop PCBA Solution



Low Heat Radiation Flexible Led PCB Assembly For Medical Lighting Driver 0 Low Heat Radiation Flexible Led PCB Assembly For Medical Lighting Driver 1 Low Heat Radiation Flexible Led PCB Assembly For Medical Lighting Driver 2 Low Heat Radiation Flexible Led PCB Assembly For Medical Lighting Driver 3
PCBA Prototype Industrial Control PCBA Telecom PCBA Medical PCBA
Low Heat Radiation Flexible Led PCB Assembly For Medical Lighting Driver 4 Low Heat Radiation Flexible Led PCB Assembly For Medical Lighting Driver 5 Low Heat Radiation Flexible Led PCB Assembly For Medical Lighting Driver 6 Low Heat Radiation Flexible Led PCB Assembly For Medical Lighting Driver 7
Automotive PCBA Consumer Electronic PCBA LED PCBA  Security PCBA





♦ Advantages of DQS Team
  1. On-time Delivery:
    • Owned PCBA factories 15,000 ㎡
    • 13 fully automatic SMT lines
    • 4 DIP assembly lines



     2. Quality Guaranteed:

    • IATF, ISO, IPC, UL standards
    • Online SPI, AOI, X-Ray Inspection
    • The qualified rate of products reach 99.9%



     3. Premium Service:

    • 24H reply your inquiry
    • Perfect after-sales service system
    • From prototype to mass production
