IATF16949 Blue Quick Turn PCB Prototyping Electronic Circuits Immersion Tin Fabrication

IATF16949 Blue Quick Turn PCB Prototyping Electronic Circuits Immersion Tin Fabrication

MOQ: 1
Price: Send us Gerber file for free quotation
Payment Terms: T/T
Supply Ability: 200,000+ m² PCB per Month
Detail Information
Layers:
1-64L
Material:
FR-4
Board Thickness:
0.2mm-3.5mm
Board Size:
50*50mm-686*508mm
Color:
Blue
Surface Treatment:
Immersion Tin
Application:
Consumer Electronic
Certificate:
UL,IATF16949,ISO&Reach
Service:
One Stop Turnkey Include Firmware,PCB&PCBA,OEM Services Provided
Supply Ability:
200,000+ m² PCB per Month
Highlight:

IATF16949 prototyping electronic circuits

,

prototyping electronic circuits PCB

,

Immersion Tin quick turn pcb fabrication

Product Description



Blue PCB Prototype Immersion Tin Manufacturing Quality Inspection


DQS Electronic offers rapid PCB prototyping services for quick-turn PCB at high quality and low cost. We're fully compliant with ISO9001:2008 quality management systems, and we have an in-house quality control department to verify that all work meets each regulation depicted by the high standards.





♦ What is PCB Prototype?



The first PCB physical board produced according to the PCB design drawings and manufacturing process requirements is used to verify the correctness of the design scheme, inspect the manufacturing quality, conduct testing and debugging, and produce product samples, etc. It can help determine whether the device meets the product design requirements.



IATF16949 Blue Quick Turn PCB Prototyping Electronic Circuits Immersion Tin Fabrication 0 IATF16949 Blue Quick Turn PCB Prototyping Electronic Circuits Immersion Tin Fabrication 1 IATF16949 Blue Quick Turn PCB Prototyping Electronic Circuits Immersion Tin Fabrication 2





♦ Key Purposes of PCB Prototyping

      1. ​Design Validation​

        • Check if the circuit works as intended (signal integrity, power delivery, etc.).
        • Test component placement and routing efficiency.
      2. ​Functional Testing​

        • Verify compatibility with other system parts (e.g., sensors, connectors).
        • Detect short circuits, open traces, or overheating issues.
      3. ​Manufacturability Assessment (DFM)​

        • Ensure the design can be reliably produced at scale (e.g., solderability, layer alignment).
      4. ​Cost & Time Optimization​

        • Fix errors early to avoid expensive rework in mass production.

​​

 PCB Prototypes Features

      • Design verification orientation: Some reliability may be sacrificed (such as temporary welding) to give priority to meeting test requirements.
      • ​​Quick response modification: After the design is changed, the proofing can be adjusted quickly (such as remaking within 24 hours).
      • Functionality priority: Do not pursue perfect appearance (such as rough silk screen printing, edge burrs), focus on ensuring that the circuit functions normally.
      • ​​Technology exploration: Often used for new technology verification (such as new components, special routing rules, etc.).



How to Order PCB Prototypes?​

  • ​​Turnkey Services​​: Companies like ​​DQS Electronic, offers low-cost, fast-turnaround prototypes in 24–72 hours.
  • ​​In-House Prototyping​​: For rapid iterations, use desktop PCB mills or laser etching (limited to simple designs).





Technical Parameters



Item

Spec

Layers

1~64

Board Thickness

0.1mm-10 mm

Material

FR-4, CEM-1/CEM-3, PI, High Tg, Rogers, PTEF, Alu/Cu Base,Ceramic, etc

Max Panel Size

800mm×1200mm

Min Hole Size

0.075mm

Min Line Width/Space

Standard: 3mil(0.075mm)  Advance: 2mil

Board Outline Tolerance

士0.10mm

Insulation Layer Thickness

0.075mm--5.00mm

Out Layer Copper Thickness

18um--350um

Drilling Hole (Mechanical)

17um--175um

Finish Hole (Mechanical)

17um--175um

Diameter Tolerance (Mechanical)

0.05mm

Registration (Mechanical)

0.075mm

Aspect Ratio

17:01

Solder Mask Type

LPI

SMT Min. Solder Mask Width

0.075mm

Min. Solder Mask Clearance

0.05mm

Plug Hole Diameter

0.25mm--0.60mm







One-Stop PCBs Solution
