High Sensitivity Sensor Commercial Lighting PCB Assembly OSP Treatment 1.5mm

High Sensitivity Sensor Commercial Lighting PCB Assembly OSP Treatment 1.5mm

MOQ: 1
Payment Terms: T/T
Detail Information
Layer:
2L
Material:
Al
Board Thickness:
1.5mm
Min. Hole Size:
0.2mm
Pin Space:
0.25mm
Surface Finish:
OSP
Testing Method:
Flying Probe
Application:
Sensor Light
Highlight:

OSP Lighting PCB Assembly

,

1.5mm Lighting PCB Assembly

,

OSP light sensor pcb

Product Description

Lighting PCB Assembly High Sensitivity Sensor Light



♦ What is Lighting PCB Assembly?



​Lighting PCB Assembly is a specialized electronic assembly that integrates circuit boards with lighting components (e.g., LEDs, drivers) and control systems. It serves as the core functional unit in diverse lighting applications, combining electrical connectivity, thermal management, and intelligent control to enable efficient, durable, and feature-rich lighting solutions.



♦ Features of Lighting PCBA:

    • ​​Intelligent Control​​: Equipped with smart sensing (e.g., auto on/off via human proximity detection) and remote functionality, including dimming, scheduling, and scene presets. Enables full-home smart control via mobile app or voice commands.

    • ​​Dimming & Speed Regulation​​: Delivers precise light intensity and device speed adjustment for optimal comfort.

    • ​High Sensitivity​​: Advanced sensor PCBAs ensure rapid and accurate human motion detection.

    • ​​Elegant Design​​: Aesthetically optimized to seamlessly integrate with diverse interior environments.



♦ Applications of Lighting PCBA:

    • Home Lighting: Like all kinds of lamps and lanterns in the family, such as chandeliers, wall lamps, table lamps, etc. can be equipped with corresponding Lighting PCBA to achieve intelligent control.

    • Commercial Lighting: Widely used in the lighting system of commercial places such as shopping malls, hotels, office buildings, etc. Lighting can be controlled according to different scenes and time to create the right atmosphere.

    • Public Lighting: Used in lighting facilities in streets, parks, squares and other public places to achieve centralised control and intelligent management through Lighting PCBA, improving lighting efficiency and energy saving.



♦ Technical Parameters



 PCB Assembly Capability



Item



                  Normal



 Special

















SMT

Assembly





PCB(used for SMT)

specification

Length and Width( L* W)

Minimum

L≥3mm,  W≥3mm

L<2mm

Maximum

L≤800mmW≤460mm

L > 1200mmW>500mm

Thickness( T)

Thinnest

0.2mm

T<0.1mm

Thickest

4 mm

T>4.5mm



SMT components specification

Outline Dimension

Min size

0201(0.6mm*0.3mm)

01005(0.3mm*0.2mm)

Max size

200 * 125

200 * 125

component thickness

T≤15mm

6.5mm<T≤15mm

QFP,SOP,SOJ

(multi pins)

Min pin space

0.4mm

0.3mm≤Pitch<0.4mm

CSP/ BGA

   Min ball space

0.5mm

0.3mm≤Pitch<0.5mm





DIP

Assembly



PCB specification



Length and Width( L* W)

Minimum

L≥50mm, W≥30mm

L<50mm

Maximum

L≤1200mm, W≤450mm

L≥1200mmW≥500mm

Thickness( T)

Thinnest

0.8mm

T<0.8mm

Thickest

3.5mm

                      T>2mm





♦ One-Stop PCBA Solution



High Sensitivity Sensor Commercial Lighting PCB Assembly OSP Treatment 1.5mm 0 High Sensitivity Sensor Commercial Lighting PCB Assembly OSP Treatment 1.5mm 1 High Sensitivity Sensor Commercial Lighting PCB Assembly OSP Treatment 1.5mm 2 High Sensitivity Sensor Commercial Lighting PCB Assembly OSP Treatment 1.5mm 3
PCBA Prototype Industrial Control PCBA Telecom PCBA Medical PCBA
High Sensitivity Sensor Commercial Lighting PCB Assembly OSP Treatment 1.5mm 4 High Sensitivity Sensor Commercial Lighting PCB Assembly OSP Treatment 1.5mm 5 High Sensitivity Sensor Commercial Lighting PCB Assembly OSP Treatment 1.5mm 6 High Sensitivity Sensor Commercial Lighting PCB Assembly OSP Treatment 1.5mm 7
Automotive PCBA Consumer Electronic PCBA LED PCBA  Security PCBA





♦ Advantages of DQS Team
  1. On-time Delivery:
    • Owned PCBA factories 15,000 ㎡
    • 13 fully automatic SMT lines
    • 4 DIP assembly lines



     2. Quality Guaranteed:

    • IATF, ISO, IPC, UL standards
    • Online SPI, AOI, X-Ray Inspection
    • The qualified rate of products reach 99.9%



     3. Premium Service:

    • 24H reply your inquiry
    • Perfect after-sales service system
    • From prototype to mass production
