ENIG SMT Electronic PCB Automotive Flex Circuit Assemblies For Body Control Modules

ENIG SMT Electronic PCB Automotive Flex Circuit Assemblies For Body Control Modules

MOQ: 1
Price: Contact our PCB engineer
Payment Terms: T/T
Detail Information
Layer:
18L
Board Thickness:
2.5mm
Min. Component Size:
01005
Surface Finish:
ENIG
Pin Space:
0.1mm
Test:
AOI,FCT,ICT
Service:
PCBA/SMT/DIP / PCBA Layout And Design
Application:
ECU
Highlight:

electronic pcb automotive

,

pcb automotive Assemblies

,

ENIG SMT flex circuit assemblies

Product Description

Wide Operating Temperature and High Reliability Automotive PCBA for Body Control Modules





♦ What's Automotive PCBA?



Automotive PCBA, is the core of automotive electronic systems.It fixes the electronic components on the PCB to form a complete circuit, which is used in various systems of the car.



♦ Features of Body Control Module PCBA

  • ​​Multi-function Control​​: Controls various body functions, such as lighting (including automatic headlights, turn signals, and interior lighting), window lifting (electric windows), door locking and unlocking (central locking system), air conditioning system regulation, wiper control (including intermittent wiper control), and seat control.
  • ​​Communication Capability​​: Communicates with other ECUs in the vehicle through protocols like CAN, LIN, or FlexRay to coordinate and control different systems.
  • ​​Power Management​​: Optimizes the working mode of electrical components to reduce power consumption when components are not in use, improving fuel efficiency in traditional vehicles and extending the range of electric vehicles.
  • ​​Diagnostics and Fault Reporting​​: Stores diagnostic data to help identify problems in the electrical system and assist maintenance personnel in troubleshooting.



♦ Types of Automotive PCB Assemblies:



​​Application​​ ​​PCB Requirements​​ ​​Examples​​
​​Engine Control Unit (ECU)​​ High-temperature resistance, EMI shielding Fuel injection, ignition timing
​​Infotainment System​​ High-speed signal integrity, multilayer Touchscreens, GPS, Bluetooth
​​ADAS (Radar/LiDAR)​​ RF/microwave PCBs, low-loss materials Collision avoidance, adaptive cruise control
​​EV Battery Management (BMS)​​ High-current PCBs, thermal management Cell balancing, charge monitoring
​​LED Lighting​​ Aluminum PCBs for heat dissipation Headlights, interior lightin





♦ DQS's PCB Assembly Capability





Item



Normal



 Special

















SMT

Assembly





PCB(used for SMT)

specification

Length and Width( L* W)

Minimum

L≥3mm,  W≥3mm

L<2mm

Maximum

L≤800mmW≤460mm

L > 1200mmW>500mm

Thickness( T)

Thinnest

0.2mm

T<0.1mm

Thickest

4 mm

T>4.5mm



SMT components specification

Outline Dimension

Min size

0201(0.6mm*0.3mm)

01005(0.3mm*0.2mm)

Max size

200 * 125

200 * 125

component thickness

T≤15mm

6.5mm<T≤15mm

QFP,SOP,SOJ

(multi pins)

Min pin space

0.4mm

0.3mm≤Pitch<0.4mm

CSP/ BGA

   Min ball space

0.5mm

0.3mm≤Pitch<0.5mm





DIP

Assembly



PCB specification



Length and Width( L* W)

Minimum

L≥50mm, W≥30mm

L<50mm

Maximum

L≤1200mm, W≤450mm

L≥1200mmW≥500mm

Thickness( T)

Thinnest

0.8mm

T<0.8mm

Thickest

3.5mm

     T>2mm
