Custom Lightweight Aluminum PCB Board Substrate For Automotive Electronics

Custom Lightweight Aluminum PCB Board Substrate For Automotive Electronics

MOQ: 1
Price: Inquiry Us
Payment Terms: T/T
Supply Ability: 200,000+ m² PCB per Month
Detail Information
Layer:
2 Layer
Thickness:
1.5 Mm
Base Material:
Aluminum
Min. Line Width/Space:
0.1/0.1mm
Copper Thickness:
0.5-4oz
Surface Treatment:
ENIG
Board Size:
Conventional
Application:
Lighting
Service:
One-stop Service
Supply Ability:
200,000+ m² PCB per Month
Highlight:

aluminum pcb board substrate

,

Lightweight aluminum pcb board

,

Lightweight pcb aluminium substrate

Product Description



Lightweight Aluminum PCB For Automotive Electronics Custom PCB Board





♦ What is Aluminum PCB?




Aluminum substrate is a functional circuit board with aluminum (or aluminum alloy) as the base material. It is mainly composed of circuit layer (copper foil), insulation layer and metal base layer. Its core value lies in efficient heat dissipation and high power carrying capacity. It is widely used in electronic devices that are sensitive to heat or require high current drive.
