Lighting PCB Assembly
Created with Pixso.

Automotive Grade Lamp White LED PCB Assembly HASL Surface Finish

Automotive Grade Lamp White LED PCB Assembly HASL Surface Finish

MOQ: 1
Payment Terms: T/T
Detail Information
Layer:
14L
Base Material:
Al
Board Thickness:
2.0mm
Min. Line Width/Spacing:
0.1mm
Surface Finish:
HASL/ENIG/OSP
PCB Assembly Method:
SMT
Application:
Automotive Lighting
Highlight:

Automotive Grade white led pcb

,

HASL white led pcb

,

HASL lamp pcb

Product Description

Automotive Grade Reliability Lighting PCB Assembly ​LED Automotive Lighting PCBA



♦ What is Lighting PCB Assembly?



​Lighting PCB Assembly is a specialized electronic assembly that integrates circuit boards with lighting components (e.g., LEDs, drivers) and control systems. It serves as the core functional unit in diverse lighting applications, combining electrical connectivity, thermal management, and intelligent control to enable efficient, durable, and feature-rich lighting solutions.



♦ Features of Automotive Lighting PCBA​​

    • ​​​​Highly reliable drive: supports PWM/analog dimming, integrated overvoltage/overcurrent protection, and ensures stable operation of LED lights (such as high and low beam lights, turn signals).
    • ​​Efficient heat dissipation: metal substrate + thermal conductive design, quickly exporting LED heat, adapting to the high temperature environment of the engine compartment.
    • ​​Intelligent control: compatible with CAN/LIN bus protocol, supports intelligent lighting functions such as adaptive front lighting system (AFS) and matrix LED.
    • ​​Optical precision: supports RGB/RGBW mixed light, realizing personalized effects such as dynamic turn indicators and daytime running light animation.



♦ Applications of Lighting PCBA:

    • ​Residential & Commercial Lighting​​: Decorative fixtures, recessed lighting, panel lights, and architectural accents.
    • Automotive​​: Interior ambient lights, dashboard backlights, and signal indicators.
    • Industrial​​: Machine indicator lights, warehouse lighting, and harsh-environment fixtures.
    • Consumer Electronics​​: Backlights for screens, keyboard illumination, and appliance status lights.



♦ Technical Parameters



 PCB Assembly Capability



Item



                  Normal



 Special

















SMT

Assembly





PCB(used for SMT)

specification

Length and Width( L* W)

Minimum

L≥3mm,  W≥3mm

L<2mm

Maximum

L≤800mmW≤460mm

L > 1200mmW>500mm

Thickness( T)

Thinnest

0.2mm

T<0.1mm

Thickest

4 mm

T>4.5mm



SMT components specification

Outline Dimension

Min size

0201(0.6mm*0.3mm)

01005(0.3mm*0.2mm)

Max size

200 * 125

200 * 125

component thickness

T≤15mm

6.5mm<T≤15mm

QFP,SOP,SOJ

(multi pins)

Min pin space

0.4mm

0.3mm≤Pitch<0.4mm

CSP/ BGA

   Min ball space

0.5mm

0.3mm≤Pitch<0.5mm





DIP

Assembly



PCB specification



Length and Width( L* W)

Minimum

L≥50mm, W≥30mm

L<50mm

Maximum

L≤1200mm, W≤450mm

L≥1200mmW≥500mm

Thickness( T)

Thinnest

0.8mm

T<0.8mm

Thickest

3.5mm

                      T>2mm





♦ One-Stop PCBA Solution



Automotive Grade Lamp White LED PCB Assembly HASL Surface Finish 0 Automotive Grade Lamp White LED PCB Assembly HASL Surface Finish 1 Automotive Grade Lamp White LED PCB Assembly HASL Surface Finish 2 Automotive Grade Lamp White LED PCB Assembly HASL Surface Finish 3
PCBA Prototype Industrial Control PCBA Telecom PCBA Medical PCBA
Automotive Grade Lamp White LED PCB Assembly HASL Surface Finish 4 Automotive Grade Lamp White LED PCB Assembly HASL Surface Finish 5 Automotive Grade Lamp White LED PCB Assembly HASL Surface Finish 6 Automotive Grade Lamp White LED PCB Assembly HASL Surface Finish 7
Automotive PCBA Consumer Electronic PCBA LED PCBA  Security PCBA





♦ Advantages of DQS Team
  1. On-time Delivery:
    • Owned PCBA factories 15,000 ㎡
    • 13 fully automatic SMT lines
    • 4 DIP assembly lines



     2. Quality Guaranteed:

    • IATF, ISO, IPC, UL standards
    • Online SPI, AOI, X-Ray Inspection
    • The qualified rate of products reach 99.9%



     3. Premium Service:

    • 24H reply your inquiry
    • Perfect after-sales service system
    • From prototype to mass production
