6 Layer Small Batch PCB Assembly Circuit Board For Electronic Manufacturing Service

6 Layer Small Batch PCB Assembly Circuit Board For Electronic Manufacturing Service

MOQ: 1
Payment Terms: T/T
Supply Ability: Post-soldering 700,000 points/day
Detail Information
Certification:
ISO, UL, IPC, Reach
Layer:
6 Layer
Material:
FR4
Board Thickness:
1.85 Mm
Surface Finish:
Immersion Gold
Pin Space:
0.2mm
Application:
Industrial Control
Supply Ability:
Post-soldering 700,000 points/day
Highlight:

6 Layer small batch pcb assembly

,

Electronic small batch pcb assembly

,

6 Layer electronic pcb assembly

Product Description


Multilayer Circuit Board PCB Assembly for Electronic Manufacturing Service



♦ What Is Electronic Manufacturing Service?


​​Electronic Manufacturing Service (EMS)​​ is a comprehensive outsourcing solution where a specialized company handles various aspects of electronics production on behalf of original equipment manufacturers (OEMs). EMS providers offer end-to-end support, enabling OEMs to focus on design, marketing, and sales while leveraging the EMS partner's manufacturing expertise.




 Key Services Provided by EMS Companies:

    1. ​​PCB Assembly​​

      • ​​SMT (Surface Mount Technology)​​: Automated placement of components on PCBs.
      • ​​Through-Hole Assembly​​: Manual or automated insertion of larger components.
    2. ​​Component Sourcing & Supply Chain Management​​

      • Procurement of electronic components (ICs, resistors, capacitors, etc.).
      • Inventory management and logistics optimization.
    3. ​​Product Design & Engineering Support​​

      • ​​DFM (Design for Manufacturing)​​: Optimizing designs for cost-effective production.
      • Prototyping, testing, and validation.
    4. ​​Box Build & System Integration​​

      • Full assembly of electronic devices, including enclosures, wiring, and final testing.
    5. ​​Testing & Quality Assurance​​

      • Functional testing, burn-in testing, and compliance with standards (e.g., ISO, IPC, RoHS).
    6. ​​After-Sales Support​​

      • Repair, refurbishment, and warranty services.



DQS Electronic Group is one of the leading EMS company in China, we provide PCB design, PCB manufacturing, PCB assembly and testing. Welcome send us your Gerber file to get free quotation. Our email: info@dqspcba.com




♦ Technical Parameters


 PCB Assembly Capability



Item



                  Normal



 Special

















SMT

Assembly





PCB(used for SMT)

specification

Length and Width( L* W)

Minimum

L≥3mm,  W≥3mm

L<2mm

Maximum

L≤800mmW≤460mm

L > 1200mmW>500mm

Thickness( T)

Thinnest

0.2mm

T<0.1mm

Thickest

4 mm

T>4.5mm



SMT components specification

Outline Dimension

Min size

0201(0.6mm*0.3mm)

01005(0.3mm*0.2mm)

Max size

200 * 125

200 * 125

component thickness

T≤15mm

6.5mm<T≤15mm

QFP,SOP,SOJ

(multi pins)

Min pin space

0.4mm

0.3mm≤Pitch<0.4mm

CSP/ BGA

   Min ball space

0.5mm

0.3mm≤Pitch<0.5mm





DIP

Assembly



PCB specification



Length and Width( L* W)

Minimum

L≥50mm, W≥30mm

L<50mm

Maximum

L≤1200mm, W≤450mm

L≥1200mmW≥500mm

Thickness( T)

Thinnest

0.8mm

T<0.8mm

Thickest

3.5mm

                      T>2mm





♦ Application Fields


6 Layer Small Batch PCB Assembly Circuit Board For Electronic Manufacturing Service 0 6 Layer Small Batch PCB Assembly Circuit Board For Electronic Manufacturing Service 1 6 Layer Small Batch PCB Assembly Circuit Board For Electronic Manufacturing Service 2 6 Layer Small Batch PCB Assembly Circuit Board For Electronic Manufacturing Service 3
PCBA Prototype Industrial Control PCBA Telecom PCBA Medical PCBA
6 Layer Small Batch PCB Assembly Circuit Board For Electronic Manufacturing Service 4 6 Layer Small Batch PCB Assembly Circuit Board For Electronic Manufacturing Service 5 6 Layer Small Batch PCB Assembly Circuit Board For Electronic Manufacturing Service 6 6 Layer Small Batch PCB Assembly Circuit Board For Electronic Manufacturing Service 7
Automotive PCBA Consumer Electronic PCBA LED PCBA  Security PCBA





♦ Advantages of DQS Team

  1. On-time Delivery:
    • Owned PCBA factories 15,000 ㎡
    • 13 fully automatic SMT lines
    • 4 DIP assembly lines


     2. Quality Guaranteed:

    • IATF, ISO, IPC, UL standards
    • Online SPI, AOI, X-Ray Inspection
    • The qualified rate of products reach 99.9%


     3. Premium Service:

    • 24H reply your inquiry;
    • Perfect after-sales service system;
    • From prototype to mass production
